Wilden® Pro-Flo® SHIFT Metal vs. Versa-Matic® Elima-Matic® Metal

You be the judge! There are many AODD pumps out there. So before you buy, review the following head-to-head comparison designed to help you find the best pump suited for your application. Wilden® Pro-Flo® SHIFT (PS) bolted pumps outperform Versa-Matic Elima-Matic pumps.


Learn More
PS-FIT-Family-Shot-medal-1
Wilden Comparison data Versa-Matic

Don't Believe Us? See the Data!

Parts Count

Parts Count Thumbnail

Parts Count

Benefits: Wilden PS pumps have fewer parts than Yamada NDP Series pumps, which means that there is a decreased chance of part failure, decreased downtime and increased savings on parts.

Max Flow

Max Flow Thumbnail

Max Flow

Benefits: Wilden PS pumps have a higher flow rate than Yamada NDP Series pumps! PS pumps can pump more product, increasing plant productivity!

Wilden PS VERSA-MATIC ELIMA-MATIC % Less Air Consumed

Efficiency
(Nm³/h/scfm)

Efficiency (Nm³/h/scfm)		 Data Points Size: 38 mm (1-1/2") Size: 38 mm (1-1/2")
227 lpm @ 2.07 bar
(60 gpm @ 30 psig)		 48/30 61/38 21%
174 lpm @ 2.62 bar
(46 gpm @ 38 psig)		 37/23 51/32 28%
Data Points Size: 51 mm (2") Size: 51 mm (2")
416 lpm @ 1.38 bar
(110 gpm @ 20 psig)		 85/53 112/70 24%
227 lpm @ 4.76 bar
(60 gpm @ 40 psig)		 48/30 64/40 25%
Data Points Size: 76 mm (3") Size: 76 mm (3")
757 lpm @ 1.38 bar
(200 gpm @ 20 psig)		 169/105 193/120 13%
378 lpm @ 2.76 bar
(100 gpm @ 40 psig)		 83/52 96/60 13%
Benefits:

Wilden PS pumps require less air to power the pump – increasing energy savings and plant productivity!
NOTE: Air supply pressure varies between pumps to meet gpm requirements.

Wilden PS VERSA-MATIC ELIMA-MATIC Wilden Annual Savings

Annual Operating Cost* (USD)

Annual Operating Cost (USD) Thumbnail		 Data Points Size: 38 mm (1-1/2") Size: 38 mm (1-1/2")
227 lpm @ 2.07 bar
(60 gpm @ 30 psig)		 $785 $995 $210
174 lpm @ 2.62 bar
(46 gpm @ 38 psig)		 $578 $804 $226
Data Points Size: 51 mm (2") Size: 51 mm (2")
416 lpm @ 1.38 bar
(110 gpm @ 20 psig)		 $1,394 $1,842 $448
227 lpm @ 4.76 bar
(60 gpm @ 40 psig)		 $762 $1,016 $254
Data Points Size: 76 mm (3") Size: 76 mm (3")
757 lpm @ 1.38 bar
(200 gpm @ 20 psig)		 $3,203 $3,660 $457
378 lpm @ 2.76 bar
(100 gpm @ 40 psig)		 $1,341 $1,547 $206

*Assumptions: Annual Operating Cost (USD) is calculated assuming that the pumps are operating at 8 hours a day, 5 days a week, totaling to 2,080 hours of operation per year at 10 cents per kilowatt hour. Air supply pressure, per published performance curves, averaged between Wilden and Versa-Matic for cost calculation.

NOTE: All information gathered and represented is published Versa-Matic performance data found Versa-Matic Elima-Matic manuals.

VERSA-MATIC® is a registered trademark of Warren Rupp, Inc.
