qf1200su qf1200su-m QF1200SU-CV QF1200SU-HT

Quattroflow 1200SU Max. Flow Rate 1200 lph

QF1200SU

  • Disposable wetted pump chamber
  • Pump chamber made of solid polypropylene
  • AC motor for operation for external VFD

QF1200SU-M

  • Pump chamber made of injection-molded polyethylene
  • Front side connections

QF1200SU-CV

  • Integrated controller
  • Digital key pad for manual operation
  • 230V motor

QF1200SU-HT

  • Integrated pump chamber, pump drive, motor and control box
  • Extended turndown ratio
  • Flexible single-phase 110-23V power supply

Technical Data

Standard Motor QF1200SU QF1200SU-M
Flow Rate Maximum Eccentric Shaft 3° 800 lph (13.3 lpm) 800 lph (13.3 lpm)
Eccentric Shaft 5° 1200 lph (20 lpm) 1200 lph (20 lpm)
Flow Rate Minimum* Eccentric Shaft 3° 10 lph (0.167 lpm) 10 lph (0.167 lpm)
Eccentric Shaft 5° 20 lph (0.333 lpm) 20 lph (0.333 lpm)
Pressure Temperature of Fluid < 40°C (104°F) 4 bar (58 psi) 4 bar (58 psi)
Temperature of Fluid > 40°C (104°F) 4 bar (58 psi) 4 bar (58 psi)
Maximum Temperature Fluid 60°C (140°F) 50°C (122°F)
Autoclave 130°C (266°F) -
Pump Speed Range rpm 30 – 2,400 30 – 2,400
Suction Lift Dry at 1800 rpm Eccentric Shaft 3° 2.5 – 3 m (8.2-9.8 ft) 2-2.5 m (6.6-8.2 ft)
Eccentric Shaft 5° 4 – 4.5 m (13.1-14.7 ft) 3-3.5 m (9.8-11.5 ft)
Volume Specifications Approximated Volume per
Revolution at Free Output
9.6 ml (5°)5.8 ml (3°) 9.6 ml (5°)5.8 ml (3°)
Filling Volume Without Connectors 75 ml 75 ml
Connection Specification (Standard) Connectors 3/4" TC 3/4" TC
Position of Connectors Inline Front
Number of Flow Directions 4 -
Product Wetted Materials (Standard) Pump Chamber PP PE injection molded**
Valve Plate PP PE injection molded
Diaphragms TPE TPE
Valves EPDM EPDM
O-rings EPDM EPDM
Certificates/Proofs (Optional) Elastomere (product wetted) USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661
USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661
Motor (Standard) Rated speed 1375 min-1 (50 Hz) 1375 min-1 (50 Hz)
Voltage 230/400 V 230/400 V
Power 0.37 kW 0.37 kW
Pump Dimension with Motor and Housing Length 497 mm (19.56") 503 mm (19.8")
Width 159 mm (6.26") 159 mm (6.26")
Height 210 mm (8.27") 210 mm (8.27")
Pump Weight with Motor and Housing 21 kg (46 lb) 20 kg (44 lb)

Other connection specifications, materials and motors available on request.
* When using pump with control box 20 lph (0.333 lpm) and 40 lph (0.667 lpm)
** Connectors PP

Standard Motor QF1200SU-CV QF1200SU-HT
Flow Rate Maximum Eccentric Shaft 5° 1200 lph (20 lpm) 1200 lph (20 lpm)
Flow Rate Minimum Eccentric Shaft 5° 10 lph (0.167 lpm) 6 lph (0.1 lpm)
Pressure Temperature of Fluid < 40°C (104°F) 4 bar (58 psi) 4 bar (58 psi)
Temperature of Fluid > 40°C (104°F) 4 bar (58 psi) 4 bar (58 psi)
Maximum Temperature Fluid 60°C (140°F) 60°C (140°F)
Autoclave 130°C (266°F) 130°C (266°F)
Pump Speed Range rpm 10 – 2200 10 – 2400
Suction Lift Dry at 1800 rpm Eccentric Shaft 5° 4 – 4.5 m (13.1-14.7 ft) 4 – 4.5 m(13.1-14.7 ft)
Volume Specifications Approximated Volume per
Revolution at Free Output
9.6 ml 9.6 ml
Filling Volume Without Connectors 75 ml 75 ml
Connection Specification (Standard) Connectors 3/4" TC 3/4" TC
Position of Connectors Inline Inline
Number of Flow Directions 4 4
Product Wetted Materials (Standard) Pump Chamber PP PP
Valve Plate PP PP
Diaphragms TPE TPE
Valves EPDM EPDM
O-rings EPDM EPDM
Certificates/Proofs (Optional) Elastomere (product wetted) USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661
USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661
Motor Rated speed 2200 min-1 2200 min-1
Voltage 230 V 110 – 230 V
Power 0.75 kW 0.485 kW
Pump Dimension with Motor and Housing Length 497 mm (19.56") 499 mm (19.65")
Width 200 mm (7.87") 200 mm (7.87")
Height 210 mm (8.27") 220 mm (8.66")
Pump Weight with Motor and Housing 21 kg (46 lb) 21 kg (46 lb)

Performance

Click on the images to enlarge.

qf1200su-chart1

QF1200SU Eccentric Shaft 5° – Liter

qf1200su-chart2

QF1200SU Eccentric Shaft 5° – Gallon

qf1200su-m-chart1

QF1200SU-M Eccentric Shaft 5° – Liter

qf1200su-m-chart2

QF1200SU-M Eccentric Shaft 5° – Gallon

QF1200SU-CV-chart1

QF1200SU-CV Eccentric Shaft 5° – Liter

QF1200SU-CV-chart2

QF1200SU-CV Eccentric Shaft 5° – Gallon

QF1200SU-HT-chart1

QF1200SU-HT Eccentric Shaft 5° – Liter

QF1200SU-HT-chart2

QF1200SU-HT Eccentric Shaft 5° – Gallon
