AODD Pumps for the Coatings Industry

Pumps for paint and coatings feature aluminum construction with PTFE or Santoprene® elastomers.

  • Liquid end made from Conductive Nylon, Polypropylene or PVDF
  • Maximum pump temperature of 189°F (87°C )
  • Maximum air pressure of 120 psi (8.2 bar)
Pump A050 A100 A150 A200 A300
Size 1/2" 1" 1-1/2" 2" 3"
Materials of Construction Aluminum with PTFE or Santoprene Elastomers Aluminum with PTFE or Santoprene Elastomers Aluminum with PTFE or Santoprene Elastomers Aluminum with PTFE or Santoprene Elastomers Aluminum with PTFE or Santoprene Elastomers
Connection FNPT (FBSPT) FNPT (FBSPT) FNPT (FBSPT), ANSI / DIN FLANGE FNPT (FBSPT), ANSI / DIN FLANGE FNPT (FBSPT), ANSI / DIN FLANGE
Max Flow 15 gpm (56.8 lpm) 48 gpm (182 lpm) 115 gpm (435 lpm) 190 gpm (719 lpm) 235 gpm (890 lpm)
Max Particle Size 1/4" (6.4 mm) 1/4" (6.4 mm) 1/4" (6.4 mm) 1/4" (6.4 mm) 7/16" (11 mm)
Max Temp 189°F (87°C)  189°F (87°C) 189°F (87°C) 189°F (87°C) 189°F (87°C)
Max Air Pressure 120 psi (8.2 bar) 120 psi (8.2 bar) 120 psi (8.2 bar) 120 psi (8.2 bar) 120 psi (8.2 bar)
View A050 View A100 View A150 View A200 View A300

AODD Pumps are designed to increase efficiency and decrease pump maintenance for businesses in the coatings industry.

In today’s highly competitive paint and coatings environment, manufacturers must more than ever control costs and eliminate production downtime. Air-operated double-diaphragm (AODD) pumps remain an essential component in the manufacture of paint and coatings. Increased demand for paint and coating material in developing markets, combined with a rebound in requirements in North American, have placed increasing operation challenges on paint manufacturers. More than ever, it remains essential that manufacturers choose an AODD that eliminates or reduces downtime while reducing overall air and energy usage.

Increasing efficiency

Whether used in the transfer of intermediate materials, pigments, or finished coating materials, air-efficient AODD pumps can significantly reduce operating cost. Consider, for example, All-Flo’s 2" model, the A200. The A200 offers increased flow rates of up to 190 gpm while reducing air consumption by up to 40%. Such efficiency and transfer gains result in very practical benefits, such as loading a 10,000-gallon tank more quickly while using less air.

Decreasing maintenance

Although maintenance is a necessary part of operations in the coatings industry, All-Flo’s simple design reduces maintenance costs since there are significantly fewer parts in the overall design. In fact, All-Flo’s air valve contains only three moving parts. With fewer parts to service or replace, your operations can resume faster than usual.

For organizations working with paint and coatings, All-Flo AODD pumps can be a great addition to your operations. To find out more about All-Flo pumps for the coatings industry, contact us today.
